DESCRIPTION

Surface stealth dropper posts offer cable-actuated bar-mounted remote activation, meaning that riders can adjust saddle height on the fly without taking hands off the bars. Surface dropper posts, in a variety of different drops, sets the benchmark for reliable performance.

MINIMAL MAINTENANCE

Replaceable self-contained pneumatic internal cartridge makes for easy maintenance.

LEVER

Major R&D has gone into lever (remote) ergonomics, resulting in a highly adjustable lever, where position can be set to fit any size hand and be fine-tuned to preferred fit. The lever is designed to be used on the left side, underbar - where the front shifter would normally sit, and is ideally suited to bikes running single ring (1x) setups.

LOW PROFILE SEATCLAMP

Low stack seat rail clamp assembly with dual bolt Micro-adjust clamp for easy, secure saddle installation.

STEALTH

Surface droppers are stealth routed, meaning that it is internally routed so that cables run inside the frame. Your frame needs to be internal dropper ready to fit a Surface dropper post.

SPECIFICATIONS

FINISH

Matte Black, Silver detailing, Laser etched details, gloss decals

SIZES AVAILABLE

Ø30.9
Insertion length/ Drop/ Post weights TBA

203mm / 100mm / Ø30.9 (605g)
233mm / 125mm / Ø30.9 (648g)
254mm / 150mm / Ø30.9 (712g)
274mm / 170mm / Ø30.9 (746g)
305mm / 200mm / Ø30.9 (795g)

DROPPER POST

Low stack seat rail clamp assembly
Dual bolt Micro-adjust clamp
Full internal cable routing
Alloy 7075-T651 material
0mm setback
Infinite height stops
Air pressure adjustable to control the rate of ascend
Minimum insertion point clearly marked on the post.

REMOTE LEVER

The infinitely adjustable remote lever enables the fully customizable ergonomic feel

Compatible with Sram MATCHMAKER.
Compatible with cable pull from both sides; remote and post.

Remote Weight	40g
Cable and Housing Weight	90g
Cable Length	1710mm
Housing Length	1500mm

FAQ

What size will work on my bike?

Refer to the handy size chart to see what length dropper will fit your bike.

Will a dropper post work on my bike?

Refer to your manufacturer to inquire about dropper compatibility on your bike model.

What kind of maintenance do I need to do on my dropper?

Refer to our maintenance and service video to see how to properly maintain your Surface dropper post.

What is the rider weight limit on the dropper?

Max rider weight limit is 120kg.
