Frame
New Frame, Updated Geometry and Hydroformed tubing, Tapered headtube, 6061 Alloy, full length cable routing, replaceable derailleur hanger, integrated mount for 40mm direct-mount 2-bolt kickstand
SPECIFICATIONS.
FRAMESET
Frame
New Frame, Updated Geometry and Hydroformed tubing, Tapered headtube, 6061 Alloy, full length cable routing, replaceable derailleur hanger, integrated mount for 40mm direct-mount 2-bolt kickstand
Headset
Steel Semi-Integrated, ZS44/28.6 ZS56/40
Frame Axle Spacing
135x9mm
Axle Specification
QR
Hanger Type
HANGER 05
SUSPENSION
Fork
Zoom 565D AMS Suspension Fork, 100mm travel, Coil, with Preload Adjust
Fork Travel
100mm
WHEELS
Wheelset
Surface Custom
Hubs
F: Alloy, 100x9mm QR, V-brake, 32H
R: Alloy, 135x9mm QR, V-brake, 32H
Rims
27.5" Alloy Rim, 32H
Tyres
Wanda P1226D 29 x 2.1", Wire bead
Max Tyre Size
2.35"
DRIVETRAIN
Crankset
Surface alloy, 42/34/24T
Max Chainring Size
42/34/24T
Bottom Bracket & Type
BSA 73mm
Shifter(s)
L: Microshift 3 Speed
R: Microshift 7 Speed
Front Derailleur
Microshift FD-M20, Dual Pull
Rear Derailleur
Microshift RD-M21L 7 Speed
Cassette
7spd 14-28T
Chain
PYC 7spd
BRAKES
Brakes
Power alloy V-brakes
COCKPIT
Grips
Surface, Push-On
Handlebar
Alloy, Ø31.8mm, 10° backsweep, 45mm rise
Stem
Surface, Alloy, Ø31.8mm, 6° rise
Saddle
Surface, Steel Rails
Seat Post
Surface, Alloy Ø30.9mm, micro adjust
Seatpost Clamp
Surface QR, Alloy
Pedals
One-Piece Alloy
WEIGHT
Bike Weight
14.84 kg (Including pedals)
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
