Frame
New Frame, Updated Geometry and Hydroformed tubing, Tapered headtube, 6061 Alloy, full length internal routing, replaceable derailleur hanger, integrated mount for 40mm direct-mount 2-bolt kickstand
SPECIFICATIONS.
FRAMESET
Frame
New Frame, Updated Geometry and Hydroformed tubing, Tapered headtube, 6061 Alloy, full length internal routing, replaceable derailleur hanger, integrated mount for 40mm direct-mount 2-bolt kickstand
Headset
Semi-Integrated, ZS44/28.6 ZS56/40
Frame Axle Spacing
135x9mm
Axle Specification
QR
Hanger Type
HANGER 22
SUSPENSION
Fork
SR Suntour XCR32 Air LOR, 100mm, Tapered Steerer, QR
Fork Travel
100mm
WHEELS
Wheelset
Custom Surface
Hubs
Shimano Centerlock TX505, 32h, F: 100 x 9mm QR, R: 135mm x 10 QR
Rims
Surface Symmetrical Double wall alloy, 23mm Internal Width, Tubeless Ready
Tyres
CST C1820 2.35", Wire bead
Max Tyre Size
2.4"
DRIVETRAIN
Crankset
Surface Alloy, 34T, 11Spd
Max Chainring Size
36T
Bottom Bracket & Type
BSA 73
Shifter(s)
Shimano 11Spd, w/o Optical gear Display
Front Derailleur
N/A
Rear Derailleur
Shimano Deore 11Spd, Shadow Plus with clutch
Cassette
Shimano 11Spd, 11-51T
Chain
KMC
BRAKES
Brakes
Tektro MD-M275 Hydraulic Disc
Rotors
Shimano SM-RT10 180/160mm
COCKPIT
Grips
Surface
Handlebar
Alloy, Oversize. 9deg backsweep, 5deg rise
Stem
Alloy 31.8MM Oversize, 10deg rise
Saddle
Surface Ergo, Steel Rails
Seat Post
Alloy 30.9mm, micro adjust
Seatpost Clamp
Alloy
Pedals
One piece alloy
WEIGHT
Bike Weight
14.92kg (Including pedals 370g)
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
