Frame
Aluminium XC/Trail frame based on the award-winning Silverback CF platform. The Silverback AL is designed around 130mm travel front & 105mm rear to provide a little extra comfort with almost no performance trade-off.
SPECIFICATIONS.
FRAMESET
Frame
Aluminium XC/Trail frame based on the award-winning Silverback CF platform. The Silverback AL is designed around 130mm travel front & 105mm rear to provide a little extra comfort with almost no performance trade-off.
Headset
Steel Semi-Integrated ZS44/28.6 ZS56/40
Frame Axle Spacing
148x12mm
Axle Specification
181x12mm P1.75
Hanger Type
HANGER 33
SUSPENSION
Fork
SR Suntour Raidon 34, 34mm stanchions, 110mm Boost, 130mm Travel
Fork Travel
130mm
Rear shock
SR Suntour RS21 EDGE-PLUS 2CR, Air Spring
Rear Suspension Travel
105mm
Shock Mounting
Body: Standard, 8x20mm
Shaft: Standard, 8x20mm
Eye-to-Eye x Stroke
210x55mm
WHEELS
Wheelset
SURFACE Custom
Hubs
F: 15x110mm, 6 Bolt, 32H
R: 12x142mm, 6 Bolt, 32H
Rims
F: SURFACE 29" Asymmetrical Alloy Rim, Tubeless Ready
R: SURFACE 29" Asymmetrical Alloy Rim, Tubeless Ready
Tyres
F: Maxxis Forekaster 29x2.35", Wire Bead
R: Maxxis Forekaster 29x2.35", Wire Bead
Max Tyre Size
2.5"
DRIVETRAIN
Crankset
Alloy Crankset, 32T, External BB
Max Chainring Size
34T
Bottom Bracket & Type
BSA 73mm
Shifter(s)
R: Microshift 1x10 Speed
Rear Derailleur
Microshift AdventX RD-M6205GM 1x10 Speed with clutch
Cassette
Microshift, 10 Speed, 11-48T
Chain
KMC X10, 10 Speed
BRAKES
Brakes
Tektro MD-M275 Hydraulic Disc
Rotors
F: Tektro 180mm, 6-Bolt
R: Tektro 180mm, 6-Bolt
COCKPIT
Grips
Surface Double Density, Lock-On
Handlebar
SURFACE Alloy Handlebar, Dia: 31.8mm, 9° Back sweep, 20mm Rise,
Stem
SURFACE Alloy Stem, 31.8mm, Rise 6°
Saddle
SURFACE
Seat Post
SURFACE Dropper with Lever, 30.9mm
Seatpost Clamp
SURFACE Alloy
Pedals
Not Included
WEIGHT
Bike Weight
16.75 kg (Size Medium, no pedals)
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
