Frame
Aluminium Gravel frameset, Custom Triple Butted Hydro-formed 6061 Frame, Flat-mount Disc Brake Mounts. Supports 700C and 650B Wheelsize, including Internal Routed Dropper Post Compatible.
SPECIFICATIONS.
FRAMESET
Frame
Aluminium Gravel frameset, Custom Triple Butted Hydro-formed 6061 Frame, Flat-mount Disc Brake Mounts. Supports 700C and 650B Wheelsize, including Internal Routed Dropper Post Compatible.
Headset
Token A83-15 Headset, ZS44/28.6 ZS56/40
Frame Axle Spacing
142x12mm
Front Axle Specification
100x12mm, P1.5
Hanger Type
HANGER 37
FORK
Fork
Aluminium, 12mm thru-axle, Disc mount
WHEELS
Wheelset
SURFACE Alloy 700C
Hubs
F: Shimano HB-RS470, 32H, OLD: 12x100mm Thru-Axle
R: Shimano FH-RS470, 32H, OLD: 12x142mm Thru-Axle
Rims
SURFACE Alloy, 700 x 25mm (21mm internal width), 32H, Tubeless Ready
Tyres
CST C1870N, 700 x 40c, Wire Bead
Max Tyre Size
45C
DRIVETRAIN
Crankset
SURFACE Alloy, 11-speed, 40T narrow-wide chainring, 170 ~ 175 mm (XS ~ XL)
Max Chainring Size
40T
Bottom Bracket & Type
BSA 68mm
Shifter(s)
Shimano GRX RX600
Rear Derailleur
Shimano RD-RX812 GRX, 11-speed, Top Normal, Shadow Plus, Direct Attachment
Cassette
Shimano CS-M5100 Deore, 11-speed, 11-42T
Chain
Shimano CN-HG601-11, 116 Links
BRAKES
Brakes
SHIMANO BR-RX410 Hydraulic Disc
Rotors
Shimano RT10 160mm
COCKPIT
Grips
Surface Seude tape, Plug with Expander Bolt
Handlebar
Surface Alloy drop bar, Ø31.8mm, Drop: 124mm, Reach 75mm, Flare: 16°, Width: 380 ~ 440mm (XS ~ XL)
Stem
Surface Alloy, Barbore: Ø31.8mm, Rise: 7°, 80 ~ 110mm (XS ~ XL)
Saddle
Surface Gravel optimised, steel rails
Seat Post
Surface Alloy Dropper, Ø27.2mm, Multi-position remote lever, Travel: 100mm
Seatpost Clamp
Surface Alloy
Pedals
Not Included
WEIGHT
Bike Weight
12.2 kg
RIDER WEIGHT LIMIT
120 kg - combined weight of bike and rider (including all kit).
