Frame
26" Butted 6061 Aluminium, Tapered 1-1/8"-1.5" headtube, 197mm x 12mm Thru Axle Dropouts, 100mm BB width
SPECIFICATIONS.
FRAMESET
Frame
26" Butted 6061 Aluminium, Tapered 1-1/8"-1.5" headtube, 197mm x 12mm Thru Axle Dropouts, 100mm BB width
Headset
ZS44/28.6 ZS56/40
Frame Axle Spacing
197x12mm
Frame Specification
224x12mm P1.5
Hanger Type
HANGER 19
SUSPENSION
Fork
Silverback Alloy Fat fork, Tapered, 15x150mm Axle
WHEELS
Wheelset
SUNRingle
Hubs
SUNRingle SRC TA, 15x150mm F / 12x197mm R
Rims
SUNringle Mulefut 80SL, Tubeless Ready
Tyres
VEE Rubber Bulldozer 26" x 4.7" MPC Tubeless
Max Tyre Size
5.0"
DRIVETRAIN
Crankset
Surface forged alloy, 170/175mm, 28T
Max Chainring Size
38/28T or 38T
Bottom Bracket & Type
BSA120
Shifter(s)
Microshift Xpress PLUS, 1x9spd
Rear Derailleur
Microshift RD-M6195M, 9spd, Active Motion RD+ with clutch
Cassette
Microshift CS-H093 11-46t, 9spd
Chain
9 speed
BRAKES
Brakes
Shimano BL-MT200 Hydraulic Disc Brakes
Rotors
F: 180mm
R: 160mm
COCKPIT
Grips
Surface
Handlebar
Surface Alloy Handlebar, Dia:31.8mm, Backsweep: 9°, Rise: 5mm; Width: 720mm
Stem
Surface Alloy Stem, 31.8mm, Rise 6°, with stainless steel bolts; 60mm
Saddle
Surface Performance Comfort
Seat Post
Surface Aluminium, 30.9mm
Seatpost Clamp
Alloy
Pedals
One Piece Alloy
WEIGHT
Bike Weight
15.55kg
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
