Frame
Alloy Trail/Enduro Frame. True single pivot design, 150mm Rear Travel. BSA Bottom Bracket. Boost 148mm
SPECIFICATIONS.
FRAMESET
Frame
Alloy Trail/Enduro Frame. True single pivot design, 150mm Rear Travel. BSA Bottom Bracket. Boost 148mm
Headset
Steel Semi-Integrated, ZS44/28.6 ZS56/40
Frame Axle Spacing
148x12mm
Axle Specification
181x12mm P1.75
Hanger Type
HANGER 3
SUSPENSION
Fork
Marzocchi Bomber Z1, 29in, 160mm travel, Rail Damper, 15x110mm Boost thru-axle, 1.5" Tapered steerer, 44mm Rake
Fork Travel
160mm
Rear shock
SR Suntour RS19 EDGE TR LOR, 185 X 55mm, Air
Rear Suspension Travel
150mm
Shock Mounting
Body: Trunnion, M10x54mm
Shaft: Standard, 8x30mm
Eye-to-Eye x Stroke
185x55mm
WHEELS
Wheelset
Silverback Custom Wheelset
Hubs
F: Shimano HB-TC500-15-B Front Hub, Centre Lock, 32H, 15mm Thru-Axle, OLD: 110mm
R: Shimano FH-TC500-HM-B Freehub, Centre Lock, 11-Speed, 12mm Thru-Axle, 32H, OLD:148mm
Rims
F: Silverback Trail Alloy 29", Tubeless Ready, 30mm Internal Width
R: Silverback Trail Alloy 29", Tubeless Ready, 30mm Internal Width
Tyres
F: Maxxis Rekon 29x2.4WT, Wire Bead
R: Maxxis Rekon 29x2.4WT, Wire Bead
Max Tyre Size
2.5"
DRIVETRAIN
Crankset
Shimano CUES FC-U4000-1, 170mm crank length, 32T chainring, 11-speed
Max Chainring Size
32T
Bottom Bracket & Type
BSA73
Shifter(s)
R: Shimano CUES SL-U6000-11R, 11-speed Rapidfire
Rear Derailleur
Shimano CUES RD-U6000, 11-speed Shadow Plus Design
Cassette
Shimano CUES CS-LG400-11, 11-speed, 11-50T
Chain
Shimano CN-LG500, 118 Links, 11-speed
BRAKES
Brakes
Shimano MT200 Front Hydraulic, 180mm Post Mount, Resin Pads
Rotors
Shimano SM-RT10, 180mm Rotor, 6-Bolt
COCKPIT
Grips
Double Density Lock-On
Handlebar
Alloy, Dia: Ø31.8mm, 9° Back sweep, 20mm Rise
Stem
Alloy, Ø31.8mm, Rise: 3°
Saddle
Silverback Ergo, Steel Rails
Seat Post
Silverback Dropper, Ø30.9mm
Seatpost Clamp
Silverback Ø30.9mm Dual Security Clamp
Pedals
Not Included
WEIGHT
Bike Weight
16.9 Kg
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
