Frame
Aluminium City Bike, Custom Triple Butted Hydro-formed 6061 Frame, Post-mount Disc Brake Mounts. Supports 700C Wheelsize. Compatible mounts for Fender and Rack installation.
SPECIFICATIONS.
FRAMESET
Frame
Aluminium City Bike, Custom Triple Butted Hydro-formed 6061 Frame, Post-mount Disc Brake Mounts. Supports 700C Wheelsize. Compatible mounts for Fender and Rack installation.
Headset
Integrated 1-1/8" to 1-1/2" Headset ZS44/28.6 ZS56/40
Frame Axle Spacing
135 x 9mm
Axle Specification
QR
Hanger Type
HANGER 25
SUSPENSION
Fork
SR Suntour NEX HLO DS 700, 63mm, Hydraulic Lockout
Fork Travel
63mm
WHEELS
Wheelset
Surface Custom
Hubs
F; Alloy, 100x9mm QR, 6 Bolt, 32H
R; Alloy, 135x9mm QR, 6 Bolt, 32H
Rims
F; Alexrims AT470 Double Wall
R; Alexrims AT470 Double Wall
Tyres
F; Kenda Kwick Drumlin, 700C x 40C
R; Kenda Kwick Drumlin, 700C x 40C
Max Tyre Size
40C
DRIVETRAIN
Crankset
SURFACE Alloy 42/34/24T
Max Chainring Size
42/34/24T
Bottom Bracket & Type
BSA73
Shifter(s)
L; Shimano ST-EF41-L Shift/Brake Lever, 3-speed
R; Shimano ST-EF41-L Shift/Brake Lever, 7-speed
Front Derailleur
Shimano FD-TY300 Tourney, Band Type 31,8mm
Rear Derailleur
Shimano Altus RD-M310-L, 7-speed
Cassette
Shimano MF-TZ500-7 Sprocket, 14-28T
Chain
PYC 7 Speed
BRAKES
Brakes
F; JAK-7 Mechanical Disc Brake
R; JAK-7 Mechanical Disc Brake
Rotors
F: 160mm
R: 160mm
COCKPIT
Grips
SURFACE Push-on Grip
Handlebar
SURFACE Alloy, Dia:31.8mm, Backsweep:9°, Rise 5mm
Stem
SURFACE Alloy
Saddle
SURFACE
Seat Post
SURFACE Aluminium
Seatpost Clamp
SURFACE QR
Pedals
One Piece Alloy
WEIGHT
Bike Weight
13.88 kg
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
