Frame
Aluminium City Bike, Custom Triple Butted Hydro-formed 6061 Frame, Post-mount Disc Brake Mounts. Supports 700C and 650B Wheelsize. Compatible mounts for Fender and Rack installation.
SPECIFICATIONS.
FRAMESET
Frame
Aluminium City Bike, Custom Triple Butted Hydro-formed 6061 Frame, Post-mount Disc Brake Mounts. Supports 700C and 650B Wheelsize. Compatible mounts for Fender and Rack installation.
Headset
Integrated 1-1/8" to 1-1/2"
Frame Axle Spacing
135x9mm
Axle Specification
QR
Hanger Type
HANGER 25
SUSPENSION
Fork
700C Alloy Rigid Fork, Tapered Steerer
WHEELS
Wheelset
Sunringle Custom
Hubs
F: Joytech, 100x9mm QR, 6 Bolt, 32H
R: Joytech, 135x9mm QR, 6 Bolt, 32H
Rims
Sunringle Helix TR-25 alloy, Tubeless Ready
Tyres
Kenda Kwick Seven.5, 27.5" x 2.0"
Max Tyre Size
2.0"
DRIVETRAIN
Crankset
SURFACE Alloy 38T
Max Chainring Size
42/34/24T or 38T
Bottom Bracket & Type
BSA73
Shifter(s)
R: Microshift Advent X 10-speed
Rear Derailleur
Microshift Advent X, 10-speed
Cassette
Shimano Deore HG50, 10-speed, 11-36T
Chain
KMC 10-Speed
BRAKES
Brakes
Shimano Hydraulic Disc
Rotors
Shimano SM-RT10 160mm
COCKPIT
Grips
SURFACE Push-on
Handlebar
SURFACE Alloy Handlebar, Dia: 31.8mm, Backsweep: 9°, Rise: 5mm
Stem
SURFACE Alloy Stem. Rise: 6°
Saddle
Surface
Seat Post
SURFACE Alloy, Dia: 27.2mm
Seatpost Clamp
SURFACE QR Clamp
Pedals
One Piece Alloy
WEIGHT
Bike Weight
12.8 kg
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
