New Step-thru Frame, with integrated carry handle, Updated Geometry and Hydroformed tubing, Tapered headtube, T6 - 6061 Aluminium, semi-internal cable routing, dropper post compatible, replaceable derailleur hanger, 142mm x 10mm QR axle dropouts, 40mm direct-mount 2-bolt kickstand mounts, water bottle bosses, 29" x 2.35" tyre clearance, removeable battery, rack and fender mounts.
Semi-integrated threadless, ZS44/28.6, ZS56/39.8
142 x 10mm
100 x 9mm
Hanger 41
Ananda 250W, 50Nm torque, 25Km/h Rear-hub Motor
504Wh In-Tube Battery, Weight: 2.56Kg. (Using LG Korea cells)
2A Charger, EU 3-Pin
Display and Remote Control
Integrated with on-bar display
SR Suntour XCM32 ATB Coil, 27.5"x2.4", 100m Travel, Ø32mm Stanchions
100mm
Surface Custom Wheelset
F: Shimano HB-QB400, QR, 36H, 100mm OLD, Disc 6-Bolt
R: Rear-Hub Motor, 36H.
F: Surface Alloy, 36H, 27.5" x 25mm, Symmetrical, Tubeless Ready
R: Surface Alloy, 36H, 27.5" x 25mm, Symmetrical, Tubeless Ready
F: CST 1879 27.5" x 2.1"
R: CST 1879 27.5" x 2.1"
2.35"
Alloy, 42T, 170mm
42T
R: Shimano Altus SL-M315-8R, 8-speed
Shimano Acera RD-M3020-8, SGS, 7/8-Speed
Shimano Acera CS-HG400-8, 11-40T, 8-Speed
KMC Z8.3
F: Shimano BL-MT200, Hydraulic Disc Brake, Resin Pads
R: Shimano BL-MT200, Hydraulic Disc Brake, Resin Pads
F: Shimano SM-RT26 180mm, 6-bolt
R: Shimano SM-RT26 160mm, 6-bolt
Surface ergo
Surface, Alloy, Dia: Ø31.8mm, Width: 740~760mm, Backsweep: 9°, Rise: 30mm
Alloy Stem, Ø31.8mm, 60mm Extension, ±6° Rise
Surface E-bike saddle
Surface Ø30.9mm lightweight Alloy
Surface Alloy
Surface, front & rear
Surface, Alloy
Surface, Alloy, 40mm direct-mount 2-bolt, adjustable foot
23.2 kg
130kg - combined weight of bike and rider (including all kit).
