Frame
Carbon Fibre Road & Gravel e-Bike frame. Aerodynamically optimized with integrated motor and Internal Battery. 700Cx40C compatible.
SPECIFICATIONS.
FRAMESET
Frame
Carbon Fibre Road & Gravel e-Bike frame. Aerodynamically optimized with integrated motor and Internal Battery. 700Cx40C compatible.
Headset
Semi-Integrated
Frame Axle Spacing
135x9mm
Axle Specification
200x10mm
Hanger Type
Hanger 34
E-BIKE
Motor
FSA System HM 1.0 250W Rear Hub-Motor, 32km/h, Torque: 42Nm
Battery
FSA System HM 1.0 250Wh Battery, 7Ah Li-Ion, Weight: 1.5kg
Charger
FSA System HM 1.0 Charger
Display
N/A
Switch
FSA System HM 1.0 Smart-LED Button
SUSPENSION
Fork
700C Carbon Fork, M12x100mm, Full Internal Cable Routing in Steerer
WHEELS
Wheelset
SURFACE Custom Wheelset
Hubs
Front: Shimano RD470, 100 OLD for 12mm Thru-axle, 6 Bolt, 28H
Rear: FSA System HM 1.0, 250Wh Hub Motor, 32H
Rims
Front: SURFACE, 700C, 21mm Internal Width and 30mm Deep, 28H
Rear SURFACE, 700C, 21mm Internal Width and 30mm Deep, 32H
Tyres
Schwalbe G-One Allround, 700x35C,TLE
Max Tyre Size
40C
DRIVETRAIN
Crankset
Shimano GRX 40T Chainring, Crank Length: 175mm
Max Chainring Size
53/39T
Bottom Bracket & Type
FSA PF30 to BB30, PF 30 BB386 EVO
Shifter(s)
Shimano GRX Hydraulic Brake and Shifter w/ Caliper
Front Derailleur
N/A
Rear Derailleur
Shimano GRX 11-Speed
Cassette
Shimano ULTEGRA 11-28T
Chain
Shimano CN-HG701-11 11-Speed
BRAKES
Brakes
Included in Brakeset or Shifter
Rotors
Shimano RT76 160mm, 6 bolt
COCKPIT
Grips
Surface Handlebar Wrap, Silicone, Plug with Expander Bolt
Handlebar
Surface, Carbon, internal routing, Dia: 31.8mm, Reach: 77mm, Drop: 128mm, Flare 16°
Stem
Surface, Carbon with internal routing, 31.8mm. Rise: 6.5°
Saddle
Surface Race, Steel Rails
Seat Post
Surface, Carbon, 42x29.3mm
Seatpost Clamp
Included with Frame
Pedals
Not Included
WEIGHT
Bike Weight
12.7kg
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
